NITROGEN : 8. Saddle adjustment
8.1 Install the saddle on the rocker (3d)
and tighten the rail clamp (3e) up to
6Nm using the half-moon bolt (3k).
8.2 Adjust the angle and the oset
of the saddle by hand tightening the
thumb screw (3j).
8.3 The rocker (3d) can be ipped to
change the saddle oset (+ / - 5mm).
8.4 The seatpost head base (3b)
can also be ipped to achieve a TRI
position. First remove the half-moon
bolt (3k) and the thumb screw (3j),
remove the top and bottom clamp (3d
& 3e) to have access to the 2 head
base screw (3c). Unscrew the screw to
remove the head base (3b) and ip it to
change the oset.
