NITROGEN : 9. Derailleur hanger adjustment
The front derailleur hanger (6) can
be adjusted according to the front
derailleur angle to get an equal curve
between the derailleur and the big
chain ring. Once at the right angle, use
blue 242 Loctite and screw both screws
in at 4Nm.
24
LOCTITE
LOCTITE
6
