NITROGEN : 10. Parts
26
No Name Supplier Description Qty SKU SKU
# Frameset parts Comp Acc
1 Nitrogen frame AG-FB-01, artwork 215A, Black / red, matte / gloss
1
2 Nitrogen fork AG-FK-01, artwork 215A-FK, Black / red, matte / gloss 1 38717 38750
# Seat post with the following parts assembled
3 Nitrogen seat post (ASP-5000) AG-SP-01, artwork 215ASP-B, Black,matte 1
3a AG-SP-01 carbon part AG-SP-01 carbon part bonded with alloy insert 1
3b Head base Head base 1
3c M5x30mm at head - A2-70 M5x30mm at head - A2-70 2
3d Lower Rail Clamp Lower Rail Clamp 1
3e Upper Rail Clamp Upper Rail Clamp 1
3f Half Moon Nut M6 Half Moon Nut M6 1
3g Half Moon Nut M5 Half Moon Nut M5 1
3h Half Moon Bolt M6 x 45mm with custom swivel head 1
3i Spherical Washer M5 Spherical Washer M5 1
3j M6 Thumbscrew M6 x 45mm thumbscrew +welded threaded rod 1
3k M5x40mm socket head M5x40mm socket head - grade 12.9 1
