3
Please check you have all the fi ttings listed below
4.5x60mm Chipboard screw x2
Tools required
A
Note: The quantities below are the correct amount to complete the assembly. In some cases more fi ttings
may be supplied than are required.
M6 Ø10x14mm Barrel nut x4
B
E
4x30mm Chipboard screw x42
C
ø7mm Cover cap plastic x28
D
Components - Fittings
Phillips
screwdriver
(medium)
6,3x50mm Assembly screw x8
Allen key
4mm incl.
Flatblade
screwdriver
(medium)
ø10mm Cover cap plastic x2
G
M6x90mm Connecting bolt x4
H
ø12x10mm Cover cap wood x2
I
No. 3939-00012-20
No. 3913-06090
No. 3938-00010-20
6,3x90mm Assembly screw x26
F
No. 3909-63090
ø10x45mm Dowel x14
J
K
No. 4008-022
No. 3930-10045
Small
hammer
Ruler/tape
measure
Eye protection
(when using a
hammer or glue)
Angle 70x40.5x20mm x2
No. 3901-40030
No. 3938-00007-20
No. 3909-63050
No. 3922-06014
No. 3901-45060
No. 4033-004
