Argos 565/7135 - Assembly Instructions; Prepare Drawer Fronts; Prepare Drawer Sides; Attach Drawer Sides to Fronts

Assembly Instructions
4
Step 1
8
x 3
x 3
x 3
x 3
B
B
B
F
F
F
F
9
10
Step 2
Prepare the 3 drawer
fronts
Screw 2 metal dowels
into each of the drawer
fronts .
Note: Tighten the metal
dowels up fully against
the panels.
B
8
Prepare the drawer
sides
Insert a small locking
cam nut into the hole
shown on the left drawer
side and the right
drawer side .
Note: The arrow on the
locking cam nut must
point towards the hole in
the edge of the panel.
Step 3
F
9
10
Attach the drawer
sides to the drawer
fronts
Push the left drawer sides
. and right drawer sides
. onto the back of the
drawer fronts .
Turn the small locking
cam nuts on the left
drawer side and right
drawer side .
Note: Turn the locking
cam nuts clockwise
to secure panels - more
than 1/2 a turn.
9
10
8
F
F
9
10
9
10
B
B
8
www.youtube.com/watch?v=InNBV_uuMmo
Drawer Assembly
