Components - Parts
Please check you have all the parts listed below
Lower rail x 2
(190.5 x 6.5 x 2.5cm)
9 Left futon mechanism
(43 x 17.5 x 5.5cm)
10 Right futon mechanism
(43 x 17.5 x 5.5cm)
11
Upper back safety rail
(190.5 x 41.5 x 2.5cm)
7
Upper side safety rail x 2
(91 x 36 x 4cm)
6
Upper front safety rail
(190.5 x 41.5 x 2.5cm)
8
Back end post x 2
(Ø5 x 165cm)
1 Front right-hand end post
(Ø5 x 165cm)
3Front left-hand end post
(Ø5 x 165cm)
2
Sticker “10” Sticker “11”
Sticker “3”Sticker “2”Sticker “1”
Lower left side rail
(89.5 x 24 x 2.5cm)
4
Sticker “4”
Lower right side rail
(89.5 x 24 x 2.5cm)
5
Sticker “5”
