Argos Malibu - Fit Runners and Prepare Cupboard Sides

Finished
front edge
Assembly Instructions
9
Step 16
Step 17
Prepare the cupboard
left side
Fit 2 hinge plates onto
the cupboard left side
making sure that the slot
is facing towards the
finished front edge.
Insert 2 large locking
nuts into the
cupboard left side as
shown.
Note: The arrow on the
locking nut must point
towards the hole in the
edge of the panel.
1
O
C
O
1
C
1
U d
U c
Runners must be
pushed up against
the drawer front
H
H
H
H
20
20
12
DL
DR
Fit runners to the file
drawer
Turn the file drawer
assembly over.
Fit runner , marked
with ‘DR’, to the bottom
edge of the right file side
. , as shown, making
sure that it is pushed up
against the back of the
file front . Use a
bradawl to mark the
fixing positions, then
secure with 2 screws .
Fit runner , marked
‘DL’, to the bottom edge
of the left file side
using the same method.
20
U d
20
12
H
U c
Right side
Left side
O
O
C
C
1
