Argos Malibu - Prepare Cupboard Right Side

2
Finished front edge
Assembly Instructions
10
Step 18
Finished
front edge
C
C
2
Prepare the cupboard
right side
a: Place a runner on
the cupboard right side
. . Slide back the top of
the runner and use the
2nd hole from the front
to fit the 1st screw .
b: Slide the runner back
the other way and use
the corresponding hole
to fit the 2nd screw .
Turn the cupboard
right side over
c: Insert 2 large locking
nuts into the
cupboard right side
as shown.
Note: The arrow on the
locking nut must point
towards the hole in the
edge of the panel.
Q
2
Finished
front edge
J
Q
Turn the cupboard right side over
J
J
C
2
2
a:
b:
c:
J
Q
Finished front edge
J
2
2
