Assembly Instructions
21
Step 41
Step 42
Fit the stool top
Lower the stool top
down onto the assembly.
Use a screwdriver to
tighten the 4 large
locking nuts fitted to
the stool left side and
stool right side .
D
17
15
16
Fit the stool drawer
Slide both the runners
forward and locate the
drawer sides and
between them, lining up
the holes in the drawer
sides with the 2nd
'threaded' holes in the
runners .
Working from the inside
of the drawer, insert 2
screws through the
drawer sides and out into
the 2nd threaded hole in
the runner.
Note: Do not overtighten
the screws .
If they catch on the
runner you may need to
loosen them slightly.
G
J
J
G
2nd threaded
hole
J
G
21 22
17
16
15
G
G
21
22
J
