Please check you have all the fittings listed below
Tools required
3
Components - Fittings
If you have damaged or missing components, call the
Customer Helpline: 03456 400800 quoting the reference
numbers below
Note: The quantities below are the correct amount to complete the assembly. In some cases
more fittings may be supplied than are required.
Rule Scissors Hammer
Eye protection
(when using a
hammer or drill)
Cross-head
screwdriver
Ruler - Use this ruler to help correctly identify the screws
mm 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170
Electric drill
(only use
when drilling
into walls)
B C
D E F
G
Small locking
nut (F3) x 4
I
A
Wooden dowel (F22) x 2 Metal dowel (F901) x 38
Large locking
nut (F900) x 34
Knock-in Peg (F171GY) x 8
M
Plastic Nail (F91) x 8
K
Wedgefix (F639) x 4
Mini block (F25) x 4
H
9mm Screw (F73) x 8
9mm Screw (F74) x 4
25mm Screw (F50) x 4
JL
JN
Handle (FBARHANDLE ) x 1
a
L b
J
Drawer runner (F1004) x 4
Strap Screw Washer x 2
Overbalance protector kit (F269) x 1
19mm Screw (F461) x 2
