Ariel JGW Series User Manual

FOR MODELS: JGW, JGR AND JGJ SECTION 1 - DESIGN SPECIFICATIONS & DATA
PAGE 1 - 4 1/01
Product Information and Safety Plates
FIGURE 1-3: TOP COVER
Oil Filter Plate with installa-
tion instructions. (See Page
4-24)
IMPORTANT SAFETY INFOR-
MATION PLATES
See Page 1-5
Information plate: Model,
Frame serial number, Stroke,
Maximum and minimum speed,
Maximum rod load, Ariel ship-
ping date, Normal lube oil
pressure, Low oil pressure
shutdown and Maximum lube
oil temperature.
ARIEL LOGO NAME
PLATE AND ADDRESS
Top Cover
Direction of Rotation
plate, located at the
drive end

Ariel JGW Series Specifications

General

Brand	Ariel
Model	JGW Series
Category	Air Compressor
Language	English
