4
Controls and Features
Figure 2: Control and Feature Locations
RT5020
RT5020
Wheel Hub Drive Pins
Disengaged
Engaged
1. Wheel Hub Drive Pins (Each Side)
2. Gas Fill
3. Engine Controls
4. Recoil Starter
5. Main Clutch Rod
6. Handlebar
7. Depth Control Stick
8. Belt Cover
1
2
3
4
5
6
7
8
1
901022 & 901422
Disengaged
Engaged
901021 & 901023
901421 & 901423
