Ariens Apex 52 User Manual

EN - 9
1. Remove wrap and packaging materials
from unit.
2. Remove unit from shipping container.
See Move Unit Manually on page 16.
3. Remove hardware from negative (-)
battery cable, but DO NOT discard.
4. Secure negative (-) battery cable to
negative (-) battery terminal with
hardware removed in
step 3.
5. Return seat to operating position. See
Figure 3.
6. Remove two bolts, two nuts, one washer
and one spacer from each side of
discharge chute bracket.
See Figure 4.
ASSEMBLY
WARNING: AVOID INJURY.
Read and understand the
Safety section before
proceeding.
Figure 3
Figure 4

Ariens Apex 52 Specifications

General

Engine Brand	Kawasaki
Engine Power	23 HP
Cutting Width	52 inches
Transmission	Hydrostatic
Deck Material	10-gauge steel
Number of Blades	3
Engine	Kawasaki FR691V
Engine Displacement	726 cc
Speed	8 mph forward/4 mph reverse
Cutting Height	1.5 - 4.5 inches
Warranty	3 years
