GB - 9
CARTON CONTENTS
ASSEMBLY
1. Unfold and adjust handlebar. See
HANDLEBAR HEIGHT on page 20.
NOTE: DO NOT bend the speed control rod
(if equipped) when unfolding the handlebars.
2. Fill engine crankcase with oil. See
engine manual.
3. Set-up mower for bagging, side
discharge or mulching. See MOWER
SET-UP on page 14.
4. Fill fuel tank. See FILLING THE FUEL
TANK on page 14.
5. Connect spark plug wire.
6. Check the engine/blade control feature.
Try starting the engine without the
engine/blade control held against the
handlebar. Engine must not start. If
engine starts, stop engine and bring the
unit to your dealer for adjustment or
repair.
ASSEMBLY
CAUTION: AVOID INJURY. Read
and understand the entire Safety
section before proceeding.
Figure 3
1. Mower Unit
2. Side Discharge Cover
3. Side Discharge Deflector
4. Literature Pack
5. Mulch Plug
6. Grass Bag
1
2
3
4
5
6
OM3190
