Ariens Compact 24 LE User Manual

Step Four: Install Remote
Deflector Cable
1. Pull rubber seal cap away from snap fitting.
2. Install snap fitting into cable bracket’s mounting hole located
under the dash.
3. Position rubber seal cap over the top of snap fitting.
4. Move deflector control lever to forward most position.
5. Attach cable eye to pin on bottom of deflector control lever.
NOTE: Hold down chute deflector cap, if needed, for more cable
slack.

Ariens Compact 24 LE Specifications

General

Brand	Ariens
Model	Compact 24 LE
Category	Snow Blower
Language	English
