Ariens Compact 24 LE User Manual

Step One: Assemble Handlebars
(Attach Control Cables)
1. Hook Spring end of attachment control cable to the clutch
arm.
2. Hook spring end of the traction control cable to the cable
eyelet on back of frame.
NOTE: Make sure cable remains in groove of pulley.
NOTE: This slide applies to
UNATTACHED handlebars ONLY

Ariens Compact 24 LE Specifications

General

Brand	Ariens
Model	Compact 24 LE
Category	Snow Blower
Language	English
