GB - 35
Wheel drive
does not
engage
1. Wheel drive control not
engaged.
2. Wheel drive belts tension too
loose.
3. Wheel drive belt worn or
damaged.
4. Wheel drive control linkage
detached or broken.
5. Bearings damaged.
6. Drive seems to slip or speed is
too slow. Inadequate traction
on sloped terrain.
7. Wheel drive rollers run in
reverse.
1. Engage wheel drive control.
2. Check wheel drive belts
tension. Adjust as necessary
(see BELT TENSION
ADJUSTMENT on page 27).
3. Replace belt. (see BELT
REPLACEMENT on
page 30)
4. Check wheel drive control
linkage. Adjust or replace as
needed. See CHECK
WHEEL DRIVE CONTROL
The unit must stop quickly
and completely when the
control is released. Adjust or
repair if necessary. See
WHEEL DRIVE CONTROL
ADJUSTMENT on page 32.
on page 19.
5. Contact your Dealer.
6. See Wheel Drive Speed
Adjustment on page 24.
See Wheel Drive Traction
Adjustment on page 25.
7. Install wheel drive lower belt
in correct orientation. See
Wheel Drive Lower Belt
Replacement on page 30.
PROBLEM PROBABLE CAUSE CORRECTION
SERVICE PARTS
Always use genuine Ariens parts to keep
your mower running like new.
Description Part Number
Air Filter 21535600
Pre-Cleaner,
Air Filter
04278300
Spark Plug 04278500
Oil Filter 04278400
Blade 04159600
Wheel Drive
Upper Belt
07200538
Wheel Drive
Lower Belt
07206000
Mower Blade
Drive Belt
07200537
ACCESSORIES
See your authorized Ariens Dealer to add
these optional accessories.
71106800 Mulching Kit, 24"
71106900 Front Swivel Wheel Kit
71107000 High-Traction Rear Tire Kit
