EN - 11
4. 911175, 179: Pull the handlebar into the
upright position. Push the bail control
handle forward and rotate handlebar to
the desired position. See Figure 5.
5. Check engine oil level and add if
necessary. See engine manual.
6. Set up mower for bagging, side
discharge or mulching. See MOWER
SET-UP on page 15.
7. Fill fuel tank. See FILLING FUEL TANK
on page 14.
8. Connect the battery (911179). See
BATTERY on page 22.
9. Connect spark plug wire.
10. Check the engine/blade control feature.
Try starting the engine without the
control handle held against the
handlebar. Engine must not start. If
engine starts, stop engine by
disconnecting spark plug while wearing
gloves. Bring the unit to your dealer for
adjustment or repair.
Figure 5
1. Handlebar
2. Bail Control Handle
911175, 179
1
2
