APPLICATION OF THE ATTACHMENTS
Hood
This accessory can be fitted to the gun nozzle to protect the nozzle end.
Extension spout
Insert the accessory by pushing it into the fixed section of the gun and aligning
the groove in the spout with the line on the
gun. Align the spout groove with the line on
the gun, then rotate the spout 90° degrees
(clockwise) in the direction of the arrow until
it locks into place.
Round brush and inclined spout
Both accessories can be fitted to the exten-
sion spout or the gun nozzle after attaching
hood.
Fabric brush with cloth and glass
wiper
The fabric brush can be attached to gun noz-
zle. The brush can be fitted with glass wiper.
Insert wiper side hooks (E1) into brush tabs
(E2) and join the two parts together. The brush
can also be fitted with a cloth cover for clea-
ning fabrics, sofas and mattresses.
E2
E1
