Two dierent setpoint temperatures at two dierent times can be selected for each day of the week: the

product will calculate the heating speed and, depending on the temperature, the best moment to start

heating in order to reach the setpoint at the desired time.

Press the MODE button to deactivate the function.

Setting the set-point

Press the MODE button to select the setpoint temperature (indicated by the temperature LEDs with the other LEDs o).

Every time the buttons are pressed, the temperature will increase or decrease by 20 degrees. After 5 seconds without

any operation, the setpoint will be conrmed and saved.

STALL STATUS

There are two possible stall statuses:

- TOUCH CONTROL STALL STATUS

If a touch control error is detected, the status of the touch LED is undetermined and cannot be controlled.

This status is indicated by the ashing of the temperature LEDs (fast if the product is on, slow if it is o).

- OTHER STALL STATUS

If other errors are detected, all the LEDs will start ashing.

To reset a non-volatile error, if possible, it is necessary to press the ON/OFF button (Fig. 3A) to switch the product

on and o. To verify which error occurred, it is necessary to enter the diagnostics state by simultaneously pressing

the ON_OFF and MODE for 3 seconds. In this state, the temperature LED must show the defect according to Table

1.4. After 25 seconds, the system will return to the stall status. Note: for the Chinese market (set through NFC), the

product is reset by simultaneously pressing the ON/OFF and ECO buttons for 5 seconds.

WI FI

To check which error has occurred, enter into the diagnostics state by pressing the ON_OFF and MODE buttons

.seconds 3 simultaneously for

WI FI

The WiFi module is switched on / o by pressing the corresponding button: if the WiFi is connected and functioning

.correctly, the corresponding LED is steady on, if the WiFi is in error (error comm), the WiFi LED is o

In idle state (WiFi switched on but not congured), the Wi LED will ash normally, so the WiFi button must be pressed

seconds if the 25 minutes (or 10 seconds to enter into AP mode: the module remains in AP mode for a maximum 5 for

AP mode has not been entered correctly, in which case it returns to the previous state). This state is indicated by the

.WiFi LED ashing rapidly

.(In the provisioning phase, the LED will ash rapidly twice and switch o once (and so on

.seconds to restore the Wi-Fi conguration 10 Press the [MODE] and [WIFI] buttons simultaneously for

the AP command and the Soft Reset command must only be used if the WiFi is enabled and an error comm is :1 NOTE

.not detected

.seconds 25 after the AP command, the WiFi button must be deactivated for :2 NOTE
