4.4 MULTIFUNCTIONAL INTERFACE
LEGENDA
1. Multifunctional LCD display 9. “Esc” button
2. “Reset” button 10. “+” button
3. Red “flame lockout” led 11. Domestic hot water temperature control knob
4. Yellow “not recovered storage” led 12. Timer (optional)
5. Pressure gouge 13. Main switch
6. Heating temperature control knob 14. Green “AUTO function ON” led
7. “-” button 15. “Auto” function button
8. “Menu/Ok” button 16. Not recovered storage knob
