Ariston 24 CF

Pag. 37 di 48
4.8.1 Open chamber collar
4.8.2 Sealed chamber inlet-exhaust collar
LEGEND
1. 60/100 inlet-exhaust collar 4. Air inlet adaptation (supplied as standard)
2. Fume analysis socket 5. Air pressure signal cover
3. Plastic cover (standard)
