Pag. 15 di 48
3 MAIN FEATURES FOR THE INSTALLER
3.1 OVERALL DIMENSIONS
3.1.1 Open chamber
LEGEND
A Central heating flow D Domestic cold water inlet
B Domestic hot water flow E Central heating return
C Gas inlet
