Pag. 35 di 48
LEGEND
1 Main storage 2 Auxiliary storage
LEGEND
1 Cool water inlet 6 Link with “main storage” (to point 5)
2 16 plates exchanger 7 DHW pump inlet
3 Hot water inlet from plate exchanger 8 DHW pump
4 To the boiler Domestic Hot Water delivery DT Storage drainage valve
5 Link with “auxiliary storage” (to point 6)
