product description
Control panel
Legend :
1. Display
2. Reset button
3. Red indicator locking light
4. Orange indicator COmfORt fonction
5. Pressure gauge
6. Heating temperature regulation knob
7. button
_
8. menu/Ok button (Programming key)
9. esC button
10. button +
11. Domestic Hot Water adjustment knob
12. Time clock
13. ON/OFF button
14. Blue indicator burner ON
15. Yellow indicator AutO fonction
16. AutO button (To active Thermoregulation)
