58
MAINTENANCE GUIDE
MAINTENANCE GUIDE: GENUS PREMIUM
4.5 GAS VALVE
GAS VALVE
Tools
Time
15 min
1
Remove the combustion
assembly (see 4.3)
Twist the gas valve anti-clockwise to
disconnect it from the fan
Bayonet
connection
1. Venturi 4. Inlet test nipple
2. Gas valve 5. Offset adjustment
3. Solenoids 6. Throttle adjustment
Page. 23 of 25
