MAINTENANCE GUIDE
2. ELECTRICAL UNIT
2.1 Control box access
Tools
TIME
4 min
Remove the front panel as above and pivot the electricl box
1
Unhook the two clip and remove the cover
2
3
2.2 Fuse
Tools
TIME
5 min
Open the control box as above
1
Remove the fuse
2
3
