Ariston GENUS PREMIUM EVO HP 85

product description
7
GENUS PREMIUM EVO HP 115/150
1
2
4
6
17
7
10
5
14
15
16
12
17
8
A
C
E
Legend:
1. Combustion analysis test point
2. Flue thermostat
3. Flame inspection glass
4. Ignition electrode
5. Ignitor
6. Modulating fan
7. Minimum water pressure switch
8. Siphon
9. Circulation pump with air release valve
10. Mixer
11. Silencer
12. Gas valve
13. Detection electrode
14. C.H. Flow temperature probe
15. C.H. Return temperature probe
16. Air relief valve
17. Connection for Safety valve
A. Central Heating Flow
C. Gas Inlet
E. Central Heating Return
