OPERATION AND FUNCTIONS
INPUT Control Object
1. Defrosting Cycle
1. COMP
2. F-FAN
3. R-FAN
4. HEATER
CONTENTS REMARKS
1. Defrosting Mode
1) Time ; 50 minutes
2) Comp. / F-fan
: ON
R-fan : Control
Heater : OFF
3) If F-sensor - 27 , then PRE-COOL becomes OFF.
1) Comp. /F-fan / R-fan : OFF
HTR : ON
2) Time limit
30 seconds : Heater is ON regardless of D-sensor
temperature right after defrosting start.
30 minutes : in case of D1-Error
80 minutes : in normal control state
, Heater Defrosting is OFF
1) Time : 7 minutes
Comp./ F-fan / R-fan / Heater / Homebar HTR : OFF
1) Time : 5 minutes
Comp. : ON
F/R-fan, Heater : OFF
Pre-Cool
Heater
Defrosting
Pause
Fan Delay
C

C
3-6. Defrosting Mode
