Page 30 Installation manual for the CD72/95/15012
AS270/AS271 INTERNAL SIREN
Note:
*) This fixing screw is used for pry-off tamper.
**) Screw to close siren.
Connection:
1. Tamper
2. Tamper
3. + 12V
4. - 0V Speaker
5. - 0V Beacon
Programming in the panel:
Connection Programming Output Panel
AS270/AS271 Description Output connection
CD72 1 Tamper terminal 30
2 Tamper terminal 31
3 + 12V terminal 11
4 - 0V Internal siren 18 Internal siren - terminal 10
5 - 0V Flash/Beacon 18 Internal siren - terminal 10
CD95/150 1 Tamper terminal 35
2 Tamper terminal 36
3 + 12V terminal 52
4 - 0V Internal siren 49 Internal siren - terminal 51
5 - 0V Flash/Beacon 49 Internal siren - terminal 51
