14 1791 999 29
Power Input 230 V AC ±10%, 50Hz, 14.5 VA
Current CS350 Quiescent: 30mA Alarm: 50mA
Consumption CD3008 Quiescent: 30mA Alarm: 50mA
Output Voltage 13.8 V DC ±5%
Normal Surge
Signalling Output Internal bell 800mA 2A
External bell 800mA 2A
Programmable 50 mA each
Outputs
Loop 6 inputs, configurable as double-pole loops using 4K7 resistors.
characteristics Response time: 300 ms.
Battery 12 V lead acid rechargeable battery (not supplied)
Backup Float charging method at 13.8 V ±5%, 800mA max.
charging current. 6.5 Ah recommmended
Auxiliary Power 13.8 V DC fused at 800mA.
Output
Note: if the combined current is greater than 800mA for the above devices, the load will be shared
by the standby battery.
Technical Specification
