Aritech IO2034NC User Manual

P/N 10-5106-501-34NC-01 • 16MAR18 3 / 24
Maintenance
Basic maintenance consists of a yearly inspection. Do not
modify internal wiring or circuitry.
Specifications
Operating voltage
17 to 28 VDC
Current consumption
Using 2 inputs
Using 4 inputs
Max. 350 µA
Max. 420 µA
Line resistance
< 100Ω
End
-of-line resistor 150KΩ, 5%, 1/4W
Optional resistor for supervised
inputs
33KΩ, 5%, 1/4W
Relay contact rating
Max. switching power
Max. switched current
Max. switched voltage
60 W
2 A
30 VDC
IP rating
IP40
Operating environment
Operating temperature
Storage temperature
Relative humidity
−10 to +55°C
−20 to +60ºC
10 to 95% noncondensing
Weight
100 g
Dimensions
175 × 124 × 51 mm
Regulatory information
This section provides a summary on the declared performance
according to the Construction Products Regulation
(EU) 305/2011 and Delegated Regulations (EU) 157/2014 and
(EU) 574/2014.
For detailed information, see the product Declaration of
Performance (available at firesecurityproducts.com
).
EU compliance
Certification body
0370
Declaration of
Performance number
10-5106-360-3001-01
Year of first CE
marking
18
Product identification
IO2034NC
Intended use
See the product Declaration of Performance
Declared performance
See the product Declaration of Performance
Manufacturer
United Technologies Safety System Co. Ltd.
80, Changjiang East Road,
QETDZ, Qinhuangdao,
Hebei Province, China 066004
Authorized EU manufacturing representative:
UTC Fire & Security B.V.
Kelvinstraat 7, 6003 DH Weert, Netherlands
2012/19/EU (WEEE directive): Products
marked with this symbol cannot be disposed
of as unsorted municipal waste in the
European Union. For proper recycling, return
this product to your local supplier upon the
purchase of equivalent new equipment, or
dispose of it at designated collection points.
For more information see:
http://www.recyclethis.info
.
Contact information
For contact information, visit firesecurityproducts.com.
Product warnings and disclaimers
THESE PRODUCTS ARE INTENDED FOR SALE TO AND
INSTALLATION BY QUALIFIED PROFESSIONALS. UTC
FIRE & SECURITY CANNOT PROVIDE ANY ASSURANCE
THAT ANY PERSON OR ENTITY BUYING ITS PRODUCTS,
INCLUDING ANY “AUTHORIZED DEALER” OR
“AUTHORIZED RESELLER”, IS PROPERLY TRAINED OR
EXPERIENCED TO CORRECTLY INSTALL FIRE AND
SECURITY RELATED PRODUCTS.
For more information on warranty disclaimers and product
safety information, please check
https://firesecurityproducts.com/policy/product-warning/
or scan
the QR code:
CS: Instalační návod
Popis
Tento dokument obsahuje informace o instalaci
vstupního/výstupního modulu IO2034NC. Modul nabízí čtyři
vstupy a čtyři výstupy a je navržen pro použití
s adresovatelnými požárními systémy FP1200C-2000C a 2X
Series.
Obrázky
Obrázek
1: Sestava modulu
Obrázek
2: Struktura modulu
(1) Kontrolka LED poruchy pro
rozpojený nebo zkratovaný
obvod hlídaných vstupů
(2)
Otočné přepínače pro
adresování modulu
(3)
Vstup zdrojového napětí
COM2 (kladný)
(4) Vstup zdrojového napětí
COM1 (záporný)
(5)
Vstupy A až D
(6)
Výstupy A až D (NC, COM,
NO)
Obrázek
3: Zapojení plně hlídaného vstupu
Obrázek
4: Příklad nastavení adresy
