ARITERM SWEDEN AB Installation, Operation & Maintenance - 2007.08.14- 2/24
CONTENTS
Important Information
.....................................................................2
Dimensions / Items included
/
Technical Specifi cation
.......... 3-4
Operating Principle
..........................................................................5
Wiring Diagram
................................................................................6
Control Panel
....................................................................................7
Installation
Chimney
........................................................................7
Water Piping - Planning
..................................................................8
Filling of Water / Burner overview
................................................. 9
Maintenance, care, sweeping
....................................................10-11
Pellets Feed System
........................................................................12
Safety and Alarms
...........................................................................13
Start-up in OFF mode
...................................................................14
Control Panel Layout - Default Settings
.....................................15
Displayed Messages
..................................................................16-17
Troubleshooting
........................................................................ 18-19
Advice about Fuel Pellets
...............................................................20
Accessories
.......................................................................................21
System Solution - Pellets Store
.....................................................22
Storage Planning
.............................................................................22
Installation Protocol.... ...................................................................23
•
Keep this instruction manual readily available for future use.
•
Read the instructions carefully before taking your pellets installation into service.
•
e capacity of the burner is calculated according to the maximum volume of pel-
lets that can be fed to and burnt in the burn pot during 1 hour (based on a normal,
average wood pellets quality as described in our fuel specifi cation)
•
Follow these instructions carefully and carry out care and maintenance work as
recommended.
Notifi cation to building authority
Attention! When you change heating installation this must always be
communicated to the local building authorities.
Inspection
Heating installations installed after
01.01.1983 shall be inspected and approved by
an authorised inspector.
e building authorities where you live can inform you about
this.
Sweeping
According to the fi re protection laws a chimney shall be swept regularly. is is done
by the local chimneysweep.
Sweeping of the boiler shall be carried out in such a
manner that good operating
economy is achieved. (see under ”Maintenance”) Prepare
to chimney-sweeping by turning off the boiler at least one hour before cleaning to
minimize the amount of glowing ash.
Wa r n i n g !
Make sure to cut the power supply to the boiler before removing the burner housing.
Maintenance contract
Ariterm recommends the boiler installation to be made by a company with professio-
nal competence. For more information please contact your Ariterm retailer.
Replacing of spare parts
Ariterm recommends that replacing of spare parts is made by authorized serviceman
of Ariterm retailer. e retailer supplies required spare parts and authorized service-
man makes the necessary adjustments and combustion gas analysis when replacing
spare parts.
Ariterm reserves the right to alter any details and specifi cations without prior notice.
IMPORTANT INFORMATION
