Arjo KWIKtrak - 7 Hfkqlfdo6 Shfl¿Fdwlrqv; Product Dimensions

001-11502-EN rev. 10
Product Dimensions 15
Product Dimensions
Product Dimensions
Dimensions
Fig. 5
Track “B”
Track “A”
Tracks
Height
AB
H90 H90 200 mm
H90 H140 253 mm
H90 H180 293 mm
H140 H140 306 mm
H140 H180 346 mm
H180 H180 386 mm
