12 www.arkrayusa.com
• The GLUCOCARD Shine Connex Meter uses two 3.0 V
lithium batteries.
• Before using the meter, check the battery compartment and
insert batteries if empty.
• When the symbol appears on the display while the meter
is in use, the batteries should be replaced as soon as possible.
• The test results may not be saved if the batteries run
out completely.
Inserting or Replacing the Batteries
Step 1
Make sure the meter is turned off.
Push the cover in the direction of the arrow
to open the battery compartment.
Step 2
Remove the used batteries and insert two
new batteries with the ‘+’ side facing up.
Make sure the batteries are inserted firmly.
Step 3
Place the cover on the battery compartment.
Push down firmly to close the cover.
A click may be heard.
NOTE
• Removing the meter batteries will not affect your stored results.
• However, meter settings may need to be reset. See page 17.
