Armada Technologies Pro900 LOCATOR USER GUIDE
19
SPECIFICATIONS
Tracking Range Depth: 8 feet (2.4 m)
(LO-F, 2kHz) Wire length: 5,000 feet (1.5 km) with direct
connection
Wire length: unlimited with broadcast mode and
leapfrogging
Tracking Signals Frequency One (LO-F): 2 kHz direct connect
Frequency Two (HI-F): 33 kHz direct connect
Frequency Three (BCAST): 175 kHz via clamp or
internal antenna
Passive AC: 50/60 Hz
Antennas Receive Peak – 2/33 kHz
Receive Null – 2/33 kHz
Receive Peak – 175 kHz
Transmit Internal – 175 kHz
Clamp Interior
Diameter 3.5 inches (85 mm)
Direct Connect
Signal Output 900 V peak with no load
1 W maximum
Audio Output Headset and Loudspeaker
Power Source Transmitter: Eight (8) ‘D’ cells (LR20) alkaline or
NiMH, or External 120 Vac Powering
Receiver: One (1) 9 V (6LR61)

Armada Pro900 Specifications

General

Brand	Armada
Model	Pro900
Category	Measuring Instruments
Language	English
