11
Complete cartridge sub
assembly
Filter screen
Gently pull off lower cartridge cap
Press the spring a few times
with a nger. This will exercise the
pilot pin (integral to spring) and clear the pilot hole.
Before reassembling the cartridge cap, make sure that the lter screen is clean
(slides out from inside of cap). When reassembling, take care to ensure the
spring is straight & locates correctly into the boss at the bottom of the cap mould-
ing.
Finally ret the cartridge into
the tap, reset the run-time &
t the handle
