1 PRODUCT BOX CONTENTS
Fit red or yellow
index pin
Basin seal
moulding
self-closing
mixer.
Run time
adjustment key
2x inlet connectors:
G3/8” male thread
to G1/2” male thread.
Outlet key
1x 2.5mm
hexagonal key
Fit blue
index pin
2x check valves, 2x lters &
2x housings
(G3/8” thread both ends)
Coloured index pins to be tted into the handle
as shown. Fit blue pin into the slot on the right.
Depending on local requirements, t either red
or yellow pin into the second slot. Discard the
extra pin.
stud type xing
kit
2x exible inlet
hoses. M8 male
to G3/8” female
