Avon 21 Self closing basin monobloc mixer
B0993AA tted with exible inlet hoses.
This Avon 21 product is a self-closing mixer designed for water economy.
The product is tted with a simple press down handle for easy actuation.
Rotation of the handle permits water temperature adjustment.
The run-time until automatic shut off is adjustable.
This product is tted with an anti-vandal outlet & exible inlet hoses.
The inlet connectors include check-valves & lters.
TABLE OF CONTENT
1 PRODUCT BOX CONTENTS .................................................................3
2 DIMENSIONS .........................................................................................4
3 WATER SUPPLY CONDITIONS ..............................................................5
4 NATIONAL PLUMBING & DRAINAGE CODE .........................................5
4.1 WATER SUPPLY CONTROLLING DEVICES (EXTERNAL) .............................................5
5 INSTALLATION GUIDE ...........................................................................6
6 FLEXIBLE HOSE GUIDELINES ..............................................................8
7 TAP OPERATION .....................................................................................8
8 OUTLET DETAILS ...................................................................................9
9 RUN TIME ADJUSTMENT .......................................................................9
10 MAINTENANCE (CLEARING PILOT HOLE) .........................................10
11 CARTRIDGE REPLACEMENT ..............................................................12
12 SPARE PARTS .......................................................................................13
12.1 (ABOVE THE BASIN ITEMS) ......................................................................................13
12.2 BELOW THE BASIN ITEMS: .......................................................................................14
13 CLEANING CHROME SURFACES .......................................................15
