Armitage Shanks Sensorflow 21 A4185AA - Default Chapter; Table of Contents

2
TABLE OF CONTENT
1 IMPORTANT PRE-INSTALLATION NOTES ...................................... 3
2 PRODUCT BOX CONTENTS ........................................................... 4
3 SUPPLY CONDITIONS ...................................................................... 5
4 WATER REGULATIONS .................................................................... 5
5 INSTALLATION GUIDE ...................................................................... 6
5.1 MOUNTING THE SENSORS ................................................................................7
5.2 PLUMBING OVERVIEW .......................................................................................8
5.3 ELECTRICAL CONNECTION ............................................................................. 10
6 SHOWER OPERATION ................................................................... 16
7 SENSOR RANGING & RUN TIME ADJUSTMENT ......................... 17
8 EXTENSION CABLES ..................................................................... 18
9 MAINTENANCE ............................................................................... 19
9.1 SOLENOID VALVE .............................................................................................19
9.2 HYGIENE FLUSH (AUTOMATIC) .......................................................................20
9.3 ISOLATING VALVE ............................................................................................. 21
10 CLEANING CHROME SURFACES ................................................. 21
11 SPARE PARTS ................................................................................. 22
12 SELECTION OF OUR FIXED SHOWER HEADS ............................ 23
Sensorow 21 panel mount showering products
  ThesepanelmountSensorow21electronicshoweringproductsaredesignedfor
water economy & hygienic “no-touch” operation.
The shower is operated by the infrared sensor which detects the presence of the users hand in the sens-
ingregion.Whenactivated,waterwillowfromtheshowerheadforthepresetrun-time.
These products are intended to be supplied with premixed or cold water.
These products are available in 3 versions: Mains powered (transformed) with option to link up to 5 link
units & independent battery powered units:
A4168AA are supplied with battery unit
A4185AA are supplied with mains power unit
A4186AA are supplied with link unit (Link up to 5 per A4185AA)
NOTE: A suitable shower head (or shower kit) should be purchased
separately (a shower head is not included with this product).
Seesection12foraselectionofourxedshowerheads.
!
