1.1.2 Available Literature for IVS 102
- Operating Instructions MG.12.Ex.yy provide the necessary information for getting the frequency converter up and running.
- Design Guide MG.12.Rx.yy entails all technical information about the frequency converter and customer design and applications.
- Programming Guide MG.12.Fx.yy provides information on how to programme and includes complete parameter descriptions.
x = Revision number
yy = Language code
Armstrong technical literature is available in print from your local Armstrong Sales Office
1.1.3 Abbreviations and Standards
Abbreviations: Terms: SI-units: I-P units:
a Acceleration
m/s
2
ft/s
2
AWG American wire gauge
Auto Tune Automatic Motor Tuning
°CCelsius
I Current A Amp
I
LIM
Current limit
Joule Energy J = N∙m ft-lb, Btu
°F
Fahrenheit
FC Frequency Converter
f Frequency Hz Hz
kHz Kilohertz kHz kHz
LCP Local Control Panel
mA Milliampere
ms Millisecond
min Minute
MCT Motion Control Tool
M-TYPE Motor Type Dependent
Nm Newton Metres in-lbs
I
M,N
Nominal motor current
f
M,N
Nominal motor frequency
P
M,N
Nominal motor power
U
M,N
Nominal motor voltage
par. Parameter
PELV Protective Extra Low Voltage
Watt Power W Btu/hr, hp
Pascal Pressure Pa = N/m² psi, psf, ft of water
I
INV
Rated Inverter Output Current
RPM Revolutions Per Minute
SR Size Related
T Temperature C F
t Time s s,hr
T
LIM
Torque limit
U Voltage V V
Table 1.1: Abbreviation and standards table .
