Installation and Maintenance
EHU-600 Series Humidifiers
13
Materials
Generator Tank Polypropylene
Cabinet Steel-18 GA with Epoxy Enamel Coating
Electrodes Type 430 Stainless Steel
Hose Cuffs EPDM Rubber
Duct Model
Disperson Tube Type 18-8 Stainless Steel
Area Fan Unit Model
EHF-2,3 Cabinet Steel –18 GA with Epoxy Enamel Coating
EHF-2 115 VAC, 60 Hz, 1.3 amp
Blower Fan 280 CFM @ 1380 RPM
EHF-3 115 VAC, 60 Hz, 2.9 amp
Blower Fan 465 CFM @ 1530 RPM
11. Capacity Chart
Chart 13-1: EHU-600 Series Capacities and Nominal Amperage Ratings
Output lb./hr. (kg/hr.) @ Voltage
Recommended
Nom
*
Branch Circuit Single Phase Three Phase
Amp MCM
Rating Module Wire Fuse 120 208 240 277 208 240 346
1
380 415
2
480 600
Model EHU-600 Humidifiers (One Steam Generator)
7.0 7 14 15 2.1(.9) 3.7 (1.7) 4.3 (2) 5 (2.3) 6 (2.7) 7 (3.2) 12 (5.5) 15 (6.8) 18 (8.2)
10.9 6 14 15 3.3(1.5) 6 (2.7) 7 (3.2) 8 (3.6) 10 (4.6) 12 (5.5) 18 (8.2) 23 (10.5) 29 (13.2)
14.6 1 15 20 4.5(2) 8 (3.6) 9 (4.1) 10 (4.6) 13 (5.9) 15 (6.8) 24 (11) 31 (14) 39 (17.8)
18.2 2 10 25 10 (4.6) 11 (5) 13 (5.9) 17 (7.7) 19 (8.7) 30 (13.7) 38 (17.3)
21.9 3 10 30 12 (5.5) 13 (5.9) 15 (6.8) 20 (9.1) 23 (10.5) 37 (16.8)
32.7 4 8 45 17 (7.7) 20 (9.1) 23 (10.5) 30 (13.7) 35 (16)
36.3 5 8 50 19 (8.7) 22 (10) 26 (11.8) 33 (15) 38 (17.3)
Model EHU-601 Humidifiers (One Steam Generator)
18.2 2 10 25 10 (4.6) 11 (5) 13 (5.9) 17 (7.7) 19 (8.7) 28 (12.8) 30 (13.7) 33 (15) 38 (17.3) 48 (21.9)
21.9 3 10 30 12 (5.5) 13 (5.9) 15 (6.8) 20 (9.1) 23 (10.5) 33 (15) 37 (16.8) 40 (18.2) 46 (21) 58 (26.4)
32.7 4 8 45 17 (7.7) 20 (9.1) 23 (10.5) 30 (13.7) 35 (16) 50 (22.8) 55 (25) 60 (27.3) 69 (31.4) 86 (39.2)
36.3 5 8 50 19 (8.7) 22 (10) 26 (11.8) 33 (15) 38 (17.3) 55 (25) 61 (27.8) 66 (30) 77 (35) 96 (43.7)
42.0 8 6 60 22 (10) 26 (11.8) 30 (13.7) 38 (17.3) 44 (20) 64 (29) 70 (32) 77 (35) 89 (40.5)
45.0 9 6 60 24 (11) 28 (12.8) 32 (14.6) 41 (18.7) 48 (21.9) 69 (31.4) 75 (34) 82 (37.3) 95 (43.3)
48.0 10 6 70 25 (11.4) 29 (13.2) 34 (15.5) 44 (20) 51 (23.2) 73 (33.2) 80 (36.4) 88 (40)
Model EHU-602 Humidifiers (Two Steam Generators)
36.4 2 8 50 19 (8.7) 22 (10) 26 (11.8) 33 (15) 38 (17.3) 55 (25) 61 (27.8) 66 (30) 77 (35) 96 (43.7)
43.8 3 6 60 23 (10.5) 27 (12.3) 31 (14) 40 (18.2) 46 (21) 67 (30.5) 73 (33.2) 80 (36.4) 93 (42.3) 116 (53)
65.4 4 3 100 35 (16) 40 (18.2) 46 (20.9) 60 (27.3) 69 (31.4) 100 (45.5) 109 (49.6) 119 (54) 138 (62.8) 173 (79)
72.6 5 3 100 39 (17.8) 44 (20) 51 (23.2) 66 (30) 77 (35) 111 (50.5) 121 (55) 133 (60.5) 153 (69.7) 192 (87.4)
84.0 8 2 125 45 (20.5) 51 (23.2) 59 (26.9) 77 (35) 89 (40.5) 128 (58.3) 140 (63.8) 153 (69.7) 177 (80.6)
90.0 9 2 125 48 (21.9) 55 (25) 64 (29) 82 (37.3) 95 (43.3) 137 (62.4) 150 (68.3) 164 (75.7) 190 (86.5)
Notes:
(1) 346 volt units require 346/200 volt 4 wire system. (2) 415 volt units require 415/240 volt 4 wire system.
KW rating = humidity output (lb./hr.) x 0.345 (for energy calculations only; not for branch circuit sizing).
*Nominal Amp Rating is for breaker sizing and UL purposes only. Average operating amperage is 88% of normal rating.
Capacitieis listed in table are based on average amperage draw.
12. Physical Data
Chart 13-2: Series EHU-600, EHF-2 and EHF-3 Fan Packages
Weights
Approximate Maximum
Model No. Shipping Operating
lb kg lb kg
EHU-600 60 27 80 36
EHU-601 76 35 104 47
EHU-602 87 40 145 66
EHF-2 33 15 32 14.6
EHF-3 34 15.5 33 15
