LISBONA 1C
LISBONA 2C
Sonda di temperatura SACET/CARREL L=4000
500
230
500
Sdef
Sdef
Sin
Sin
Sout Sout
Sonda termostato fine sbrinamento o MPX
o termometro termostato IR 32
Sin
Sonda aspirazione aria
Sonda mandata aria centralina MPX
Sout
Sdef
Sin
Sout
Sdef
MPX End-defrost thermostat probe
Air OFF probe
MPX air ON probe controller
or IR 32 thermostat
