ARNOTT COIL SPRING CONVERSION KIT
FOR
1999-2006
MERCEDES-BENZ S-CLASS (W220 CHASSIS)
12. LOOSEN THE LOWER CONTROL BOLT SLIGHTLY (THIS WILL ALLOW THE LOWER CONTROL ARM TO SWING
DOWN. (FIGURE 20-11)
13. REMOVE SHOCK ASSEMBLY FROM CAR. (FIGURE 20-12)
14. REMOVAL COMPLETE.
FIGURE 20-11
FIGURE 20-12
REAR COIL STRUT INSTALLATION
1. INSTALLATION IS IN REVERSE ORDER OF REAR AIR STRUT REMOVAL.
Tighten all nuts and bolts to manufacturer's specications during the installation process.
