Arnott SK-2806 - Final Strut Removal Steps

4
REV 3 09/23/2016
SK-2806
SK-2806
ARNOTT FRONT SHOCK KIT
FOR
2007-2014
GM FULL SIZE SUVs
FIGURE 10-8 FIGURE 10-9
4. REMOVE THE TWO (2) LOWER MOUNTING BOLTS. (FIGURES 10-8, 10-9)
5. LOOSEN, DO NOT REMOVE, THE SWAY BAR END LINK HARDWARE. (FIGURE 10-10)
FIGURE 10-10
6. CAREFULLY REMOVE COIL STRUT FROM THE VEHICLE. (FIGURE 10-11)
FIGURE 10-11
