REV 3 09/23/2016
SK-2806
SK-2806
ARNOTT FRONT SHOCK KIT
FOR
2007-2014
GM FULL SIZE SUVs
COIL SENSOR INSTALLATION
1. INSTALL THE COIL SENSOR, PROVIDED IN THIS KIT, ONTO THE TOP OF THE SHOCK ROD. TIGHTEN UNTIL
SECURE. (FIGURE 40-1, 40-2)
FIGURE 40-1 FIGURE 40-2
FIGURE 40-3 FIGURE 40-4
2. CONNECT THE VEHICLE’S ELECTRICAL CONNECTOR TO THE COIL SENSOR. (FIGURES 40-3, 40-4)
