Arnott SK-2806 - Arnott Front Shock Kit Shock Disassembly and Component Removal; Separating Shock Rod and Spring Assembly

5
REV 3 09/23/2016
SK-2806
SK-2806
ARNOTT FRONT SHOCK KIT
FOR
2007-2014
GM FULL SIZE SUVs
Use a spring compressor tool for the following removal steps.
SHOCK REMOVAL
1. RELEASE CLIP AND REMOVE THE TOP ELECTRICAL CONNECTOR AND SHOCK ROD STEM.
(FIGURES 20-1, 20-2, 20-3, 20-4)
FIGURE 20-1 FIGURE 20-2
FIGURE 20-3 FIGURE 20-4
