Arnott SK-2806 - Arnott Front Shock Kit Coil Strut Reassembly and Installation; Arnott Coil Strut Reassembly Guidelines; Arnott Coil Strut Installation Procedure

7
REV 3 09/23/2016
SK-2806
SK-2806
ARNOTT FRONT SHOCK KIT
FOR
2007-2014
GM FULL SIZE SUVs
COIL STRUT REASSEMBLY
Tighten all nuts and bolts to manufacturer's specications during the assembly process.
1. ASSEMBLY IS IN REVERSE ORDER OF SHOCK D ISASSEMBLY.
FIGURE 30-1
COIL STRUT INSTALLATION
Tighten all nuts and bolts to manufacturer's specications during the installation process.
1. INSTALLATION IS IN REVERSE ORDER OF SHOCK REMOVAL.
2. POSITION THE T-BAR ON TOP OF THE CONTROL ARM TO ENSURE PROPER MOUNTING. (FIGURE 30-1)
