12
Connecting the Diffuser to HVAC.
Refer to the AromaPro HVAC Connection Diagram FIG A.
The AromaPro is a versatile and powerful commercial scent diffuser. If you decide to
connect it to your HVAC system follow the below steps. Diffusing the scent via HVAC will
allow you to cover multiple rooms and zones. To scent the right zones, check with your
HVAC provider or Mechanical Engineer to determine which HVAC unit to connect to.
NOTE: The AromaPro can cover 4,000 sq.ft. of space. If you have more then 4,000 sq.ft.
you will require a larger unit from our Air Stream line.
1. You will want to choose the air handler you want to connect to. If you have multiple air
handlers select the one that will cover the area you wish to be scented. Consult your
HVAC supplier if needed.
2. With a metal drill bit designed to drill through sheet metal, drill a hole the size of the
hose guide in the air duct directly after the blower. Make sure you are tapping into the
supply side of your duct, not the return side.
3. IMPORTANT: Never install before the coils or filters as the filters will dilute the scent
and you will not get the same result.
4.Once the hole is made, insert the hose guide. The hole on the end of the hose guide
should be pointing with the air flow not against it. This allows the scent to travel in the
same direction as the air flow.
5. Secure the hose guide by screwing it to the duct.
6. Screw in the supplied HVAC adaptor into the hose guide.
7. Take a second HVAC adaptor and screw it into the AromaPro.
8. Either wall mount the AromaPro to the duct, the wall or place on a shelf directly
under the Scent Point connection. It’s important to keep the AromaPro as close as
possible to the scent point. MAX AIR TUBE LENGTH SHOULD BE 3 FEET.
9. Cut supplied air tube to length to go from the AromaPro to the hose guide.
The distance between the AromaPro and hose guide should be as short as possible.
MAX 3 FEET. Do not leave any slack. Coiling or excess of the air tube will create air
pockets and buildup of scent inside the tube.
10. Connect the AromaPro to the 110V-240V plug and set the timer.
