3600 SERIES USER MANUAL
3600 Series Programmable DC Power Supply
VERSION 2.10 2006.03
11
2.3.2 Setting the maximum power
When you select the “Max Power Set” function, the LCD will display:
Max Power=108.00W
New= W
Set the maximum output power by using the number keyboard or the
rotary knob, then press “Enter” for confirmation.
2.3.3 Enable/disable the rotary knob
The “Rotary Knob Set” function is to enable or disable the rotary knob. When you select the “Rotary Knob Set”
function, the LCD will display:
Sw Enable Def *
Sw Disable
Use the UP and DOWN keys or the rotary knob to select, and press
“Enter” to confirm.
2.3.4 Setting initial output state
The “Initial Out Set” function is used to set the output state (conditions) when switching on the 3600 Power
Supply the next time it is used.
Select “Ini. Out Save” to save the current output state before switching off.
If the current output is on, next time the 3600 is switched on, the output will be in the "ON" mode;
If the current output is off, the next time the 3600 is switched on, the output will be in the "OFF" mode.
Selecting “Ini. Clear Def”, will ensure that the output is in the "OFF" mode each time the 3600 Power Supply is
switched on.
Ini. Out Save
Ini. Clear Def *
Use the UP and DOWN keys or the rotary knob to select, and press
“Enter” to confirm.
2.3.5 Save voltage setting
The “Volt. Save Set” function is to set whether to save the voltage setting. Select “Save Out Volt.”, the set voltage
value will be saved in nonvolatile memory, and couldn’t be lost even if the 3600 is switched off. When switching on
the next time, the voltage value will be automatically reloaded. Select "Don’t Save Def”, the default value (0V) will
be loaded every time switching on.
Save Out Volt.
Don’t Save Def*
Use the UP and DOWN keys or the rotary knob to select, and press
“Enter” to confirm.
2.3.6 Setting Baud Rate
This function is used to set the communication baud rate.
When you select “Baud Rate Set” function, the LCD will display :
